We have 3 different type of Melt blown equipment in our plant.
We’re glad to assist your production test for new product development and fabric confirmation before improvement or launching a new line etc by three Melt blown equipment in our plant. Each machine has its own characteristics, and it is possible to select ideal testing equipment according to your request. For example, mixture two-components materials, Mixing fiber, Nanofiber, and Super Engineering plastics etc.
Flows
1
Inquiry
We will explain our equipment and ask your demand.
2
Confirm the target and specs and estimate.
Issue the estimate after clarify of testing range and purpose.
3
Operate the test
You can join the test and share the conditions.
4
Evaluation
We ship sample to you, please evaluation on your country.
5
Support meeting
If you can move on next step, we will discuss what to do after get the your evaluation result.
Lineup for Testing Melt blown Equipment
Vertical type,
Conjugation type
Machine is capable to made widely product, start from nano fibers to Bi-component nonwven
| Spinneret line up | Hole | Pitch | Number of Holes | Spinneret Angle |
|---|---|---|---|---|
| Φ0.15 | 0.25 | 1801 | 60 | |
| Φ0.2 | 0.36 | 1251 | 60 | |
| Φ0.25 | 0.4 | 1126 | 60 | |
| Φ0.3 | 0.45 | 1001 | 60 | |
| Extruder | Single-screw extruder Φ32mm×2sets | |||
| Throughput | MAX40kg/hour（while using 2sets extruder） | |||
| Spinning temperature | MAX380℃ | |||
| Maximum pressure | 10Mpa (Usually by 4Mpa) | |||
| Air flow | MAX6㎡/min | |||
| Conveyor speed | MAX60㎡/min | |||
Horizontal type,
durm collecting type
Smaller testing machine. The short residence of material design, it’s capable to test with high add value polymer such as PLA etc.
| Spinneret line up | Hole | Pitch | Number of Holes | Spinneret Angle |
|---|---|---|---|---|
| Φ0.1 | 0.5 | 451 | 60 | |
| Φ0.2 | 0.5 | 451 | 60 | |
| Φ0.3 | 0.5 | 451 | 60 | |
| Extruder | Single-screw extruder Φ25mm | |||
| Throughput | MAX4kg/hour | |||
| Spinning temperature | MAX380℃ | |||
| Maximum pressure | 4MPa | |||
| Air flow | MAX3.2㎡/min | |||
| Conveyor speed | MAX20㎡/min | |||
Horizontal type,
conveyor collecting type
The most compact machine in the line up and it’s capable to test with high add value polymer such as PPS etc.
| Spinneret line up | Hole | Pitch | Number of Holes | Spinneret Angle |
|---|---|---|---|---|
| Φ0.1 | 0.25 | 601 | 60 | |
| Φ0.7 | 1.16 | 130 | 60 | |
| Extruder | Single-screw extruder Φ25mm×2台 | |||
| Throughput | MAX4kg/hour | |||
| Spinning temperature | MAX380℃ | |||
| Maximum pressure | 4MPa | |||
| Air flow | MAX2.39㎡/min | |||
| Conveyor speed | MAX60㎡/min | |||
